製品詳細
起源の場所: 中国
ブランド名: JGPV
モデル番号: A42H-16C
支払いと送料の条件
最小注文数量: 1セット
価格: USD49.9/pc - USD4289.9
パッケージの詳細: 合板ボックスの安全梱包
受渡し時間: 14日間
支払条件: L/C、T/T、ウェスタンユニオン
供給の能力: 1ヶ月あたり1000個
標準または非標準: |
標準 |
応用: |
一般的な |
生産の節分: |
産業弁 |
目的: |
重圧保護 |
中型: |
空気,水,蒸気,石油,石油ガスなど |
使用温度: |
摂氏300度まで |
定数圧力: |
低温,中温,高温 |
製造業: |
鋳造 |
接続口径: |
DN15-DN300 |
品質保証: |
18ヶ月 |
名前: |
安全弁 |
標準または非標準: |
標準 |
応用: |
一般的な |
生産の節分: |
産業弁 |
目的: |
重圧保護 |
中型: |
空気,水,蒸気,石油,石油ガスなど |
使用温度: |
摂氏300度まで |
定数圧力: |
低温,中温,高温 |
製造業: |
鋳造 |
接続口径: |
DN15-DN300 |
品質保証: |
18ヶ月 |
名前: |
安全弁 |
Cast Steel And Stainless Steel Automatic Pilot Operated Safety Valve
Pilot operated safety valve is a type of non direct load safety valve composed of a main valve and a pilot valve (also known as a "secondary valve"). The main valve is driven by the medium discharged from the pilot valve. Due to the pulse form of pressure in the system, it is also known as a "pulse safety valve".
This automatic valve category is mainly used on boilers, pressure vessels, and pipelines to control pressure not exceeding specified values, providing important protection for personal safety and equipment operation.
| Parameter | Specification |
|---|---|
| Nominal diameter DN(mm) | DN15-DN300 |
| Nominal pressure PN(MPa) | 1.0-32.0 |
| Strength test (Water) | 1.5 times of pressure nominal |
| Set pressure test (Air) | 0.9 times of pressure nominal |
| Main components - Body | WCB, CF8, CF8M, CF3, CF3M |
| Main components - Bonnet | WCB, CF8, CF8M, CF3, CF3M |
| Main components - Disc | WCB, CF8, CF8M, CF3, CF3M |
| Main components - Spring | 50CrVA |
| Main components - Stem | WCB, CF8, CF8M, CF3, CF3M |
| Applicable medium | Water, air, petroleum gas and weak corrosive medium |
| Working temperature | ≤300℃ |
| Connection method | Flange connection |
Note: While offering superior sealing, pilot operated safety valves have more complex structures and may not respond as quickly as direct acting safety valves.
